Brass Filter Ball Valve
SKU
BV5043
Compatible file extensions to upload:
£18.54
£18.54
Available to Order
Key Features
- Brass Filter Ball Valve
- Built-in Filter Mesh
- Brass Body
- Screwed BSPP
- Sizes: 1/2" to 2"
Related Products
Brass Ball Valve BSI with Neck Extension
Price on Application
Brass Ball Valve BSI with Neck Extension
Price on Application
Brass Ball Valve BSI with Neck Extension
Price on Application
Details
Brass Ball Valve with Built-in Filter Mesh
This 2 way Brass Ball Valve features a built-in filter mesh that offers space saving with regards to conventional Y type strainers.
An easy to clean ball valve that offers perfect open / close operation with PTFE Seals and screwed BSPP end connections in sizes 1/2" to 2".
Key Features:
- Brass Filter Ball Valve
- Built-in Filter Mesh
- Brass Body
- PTFE Seals
- NBR O Ring
- Filter: Stainless Steel 304 & Nylon
- Screwed BSPP
- Sizes: 1/2" to 2"
- Pressure Rated: PN30 (1/2″ to 1″), PN20 (1 1/4″ to 2″)
- Temperature -20°C to 100°C
Technical Attributes
| End Connection | BSP |
|---|---|
| Body Material | Brass |
| Seal Material | PTFE |
| Size | 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50) |
| Design | Female x Female, Built In Filter |
| Industry / Approvals | General / Industrial / Process, HVAC |
| Lever | Manual Lever |
| Temperature Range | -20°C to 100°C |
| Pressure | Up to: PN30 (1/2″ to 1″), PN20 (1 1/4″ to 2″) |
| Actuatable? | No - Manual Only |
| Manufacturer | VOLT |
